You cannot specify port value displays through the command line interface. Simulink does not display the input values to the merge block. Command-Line Simulationsįor efficiency, Simulink does not support port value displays during a command-line simulation using the Value that is driving the blocks displays instead of the block values. When you display port values on Signal Specification and Inport blocks in a subsystem, the Signal Specification Block and Inport Block Port value displays do not honor refine factor values ( Configuration Parameters > Data Import/Export > Additional parameters > Refine factor) because Simulink updates port value displays only during major time steps. When stepping back, if the port value is unavailable, the If you do not enable port value display when stepping forward, the display will not beĪvailable when stepping back. Simulink does not display data for the ports of an enabled subsystem that is not Outport block, depending on the Output when disabled That goes into an Outport block displays the value of the
When you disable a conditionally executed subsystem, the port value display for a signal You can also display values on signal lines outside of the variant However, you can display port values within the subsystems contained in the variant In such cases, during simulation, Simulink automatically determines block connectivity based on the active variant. There are no signal lines connecting to them. You cannot display port values for subsystems contained in a variant subsystem when
